Figure 91. Installing the expansion card riser (Riser 4)
Next steps
1. If required, re-connect the cables to the expansion card.
2. Follow the procedure listed in After working inside your system.
3. Install any device drivers required for the card as described in the documentation for the card.
Removing expansion card from the expansion card riser
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
3. If applicable, disconnect the cables from the expansion card.
Steps
1. Pull and lift the expansion card retention latch lock to open.
NOTE:
Pull the black card holder before removing the card from the riser.
Installing and removing system components 109
