Dell Latitude D630 User Manual

Using the Display 45
NOTICE: You can damage an external monitor by using an unsupported refresh rate. Before adjusting the refresh
rate on an external monitor, see the user’s guide for the monitor.
Dual Independent Display Mode
You can attach an external monitor or projector to your computer and use it as an extension of your
display (known as "dual independent display" or "extended desktop" mode). This mode allows you to use
both screens independently and drag objects from one screen to the other, effectively doubling the
amount of viewable work space.
1
Connect the external monitor, TV, or projector to the computer.
2 Under Pick a category , click Appearance and Themes .
3 Under Pick a task... , click the area you want to change, or under or pick a Control Panel icon , click
Display .
4 In the Display Properties window, click the Settings tab.
NOTE: If you choose a resolution or color palette that is higher than the display supports, the settings adjust
automatically to the closest supported values. For more information, see your operating system documentation.
5 Click the monitor 2 icon, click the Extend my Windows desktop onto this monitor check box, and
then click
Apply .
6 Change Screen resolution to the appropriate sizes for both displays and click Apply .
7 If prompted to restart the computer, click Apply the new color setting without restarting and click
OK .
8 If prompted, click OK to resize your desktop.
9 If prompted, click Yes to keep the settings.
10 Click OK to close the Display Properties window.
To disable dual independent display mode:
1
Click the Settings tab in the Display Properties window.
2 Click the monitor 2 icon, uncheck the Extend my Windows desktop onto this monitor option, and
then click
Apply .
If necessary, press <Fn><F8> to bring the screen image back to the computer display.
Swapping Primary and Secondary Displays
To swap your primary and secondary display designations (for example, to use your external monitor as
your primary display after docking):
1
Click the Start button and click Control Panel .
2 Under Pick a category , click Appearance and Themes .

Dell Latitude D630 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	667 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
3D	No
AC adapter included	Yes
Disc types supported	CD, DVD
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	80 GB
Number of HDDs installed	1
Pixel pitch	0.2373 x 0.2373 mm
Display diagonal	14.1 \
Display brightness	220 cd/m²
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Maximum on-board graphics card memory	- GB
On-board graphics card dynamic frequency (max)	- MHz
Speaker power	2 W
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Premium
Operating system architecture	64-bit
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Operating shock	143 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	163 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Tcase	- °C
Bus type	FSB
Stepping	M0
Tjunction	100 °C
Processor cache	2 MB
Processor cores	2
Processor model	T7250
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T7000 Series
Processor socket	Socket 478
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	2 GHz
Processor cache type	L2
Configurable TDP-down	- W
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	10
Number of Processing Die Transistors	291 M
Processor code	SLA49
Processor ARK ID	31728
Processor package size	35 x 35 mm
Graphics & IMC lithography	- nm

Weight and Dimensions

Depth	238 mm
Width	337 mm
Height	32.3 mm
Weight	2270 g
