Dell Latitude D630 User Manual

78 Troubleshooting
4 When the tests are completed, if you are running the Dell Diagnostics from the Drivers and Utilities
media , remove the media.
5 When the tests are complete, close the test screen to return to the Main Menu screen. To exit the Dell
Diagnostics and restart the computer, close the
Main Menu screen.
Dell Support Utility
The Dell Support Utility is installed on your computer and available from the Dell Support icon on the
taskbar or from the Start button. Use this support utility for self-support information, software updates,
and health scans of your computing environment.
Accessing the Dell Support Utility
Access the Dell Support Utility from the Dell Support icon on the taskbar or from the Start menu.
If the Dell Support icon does not appear in your taskbar:
1
Click the Start button and point to Programs .
2 Click Dell Support and point to Dell Support Settings .
3 Ensure that the Show icon on the taskbar option is checked.
NOTE: If the Dell Support Utility is not available from the Start menu, go to support.dell.com and download the
software.
The Dell Support Utility is customized for your computing environment.
The Dell Support icon in the taskbar functions differently when you click, double-click, or right-click the
icon.
Clicking the Dell Support Icon
Click or right-click the icon to perform the following tasks:
• Check your computing environment
Configuration Displays your hardware configuration for the selected
device.
The Dell Diagnostics obtains configuration information
for all devices from system setup, memory, and various
internal tests, and it displays the information in the
device list in the left pane of the screen. The device list
may not display the names of all the components
installed on your computer or all devices attached to your
computer.
Parameters Allows you to customize the test by changing the test
settings.
Tab Function (continued)

Dell Latitude D630 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Grey
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	667 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
3D	No
AC adapter included	Yes
Disc types supported	CD, DVD
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	80 GB
Number of HDDs installed	1
Pixel pitch	0.2373 x 0.2373 mm
Display diagonal	14.1 \
Display brightness	220 cd/m²
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Maximum on-board graphics card memory	- GB
On-board graphics card dynamic frequency (max)	- MHz
Speaker power	2 W
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Premium
Operating system architecture	64-bit
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Operating shock	143 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	163 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Tcase	- °C
Bus type	FSB
Stepping	M0
Tjunction	100 °C
Processor cache	2 MB
Processor cores	2
Processor model	T7250
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T7000 Series
Processor socket	Socket 478
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	2 GHz
Processor cache type	L2
Configurable TDP-down	- W
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	10
Number of Processing Die Transistors	291 M
Processor code	SLA49
Processor ARK ID	31728
Processor package size	35 x 35 mm
Graphics & IMC lithography	- nm

Weight and Dimensions

Depth	238 mm
Width	337 mm
Height	32.3 mm
Weight	2270 g
