2. Install the hinge caps.
3. Install the plastic display assembly or aluminum display assembly (whichever applicable).
4. Install the wireless card.
5. Install the M.2 2230 solid state drive or M.2 2280 solid state drive (whichever applicable).
6. Install the base cover.
7. Install the SD card.
8. Follow the procedure in After working inside your computer.
Display panel
Removing the display panel
CAUTION: The information in this section is intended for authorized service technicians only.
NOTE: This procedure is applicable for systems shipped with a plastic chassis only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the M.2 2230 solid state drive or M.2 2280 solid state drive (whichever applicable).
5. Remove the wireless card.
6. Remove the plastic display assembly.
7. Remove the hinge caps.
8. Remove the display bezel.
9. Remove the hinges.
About this task
The following images indicate the location of the display panel and provide a visual representation of the removal procedure.
106
Removing and installing Field Replaceable Units (FRUs)
