Next steps
1. Install the 3-cell battery or 4-cell battery (whichever applicable).
2. Install the base cover.
3. Install the SD card.
4. Follow the procedure in After working inside your computer.
Touchpad
Removing the touchpad
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the 3-cell battery or 4-cell battery (whichever applicable).
About this task
The following images indicate the location of the touchpad and provide a visual representation of the removal procedure.
Steps
1. Remove the four (M2x2) screws that secure the touchpad bracket to the palm-rest and keyboard assembly.
Removing and installing Field Replaceable Units (FRUs)
69
