4. Install the display bezel.
5. Install the hinge caps.
6. Install the plastic display assembly.
7. Install the wireless card.
8. Install the base cover.
9. Install the SD card.
10. Follow the procedure in After working inside your computer.
Removing the camera module (with aluminum chassis)
CAUTION: The information in this section is intended for authorized service technicians only.
NOTE: This procedure is applicable for systems shipped with alumunium chassis only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the wireless card.
5. Remove the aluminum display assembly .
6. Remove the hinge caps.
7. Remove the display bezel.
8. Remove the hinges.
9. Remove the display panel.
10. Remove the eDP cable.
About this task
The following images indicate the location of the camera module (in a system shipped with an aluminum chassis) and provide a
visual representation of the removal procedure.
Removing and installing Field Replaceable Units (FRUs)
121
