Numb
er
Components
1 WLAN Antenna (Main)
2 WLAN Antenna (Auxiliary)
Steps
After performing the pre-requisites, you are left with the palm-rest and keyboard assembly.
Installing the palmrest and keyboard assembly
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
Steps
NOTE: For systems with aluminum chassis, both the left and right RF metal brackets MUST be transferred to the
replacement palm-rest assembly.
For systems with a 3-cell battery:
For systems with a 4-cell battery:
Removing and installing Field Replaceable Units (FRUs)
139
