6. Install the wireless card.
7. Install the M.2 2230 solid state drive or M.2 2280 solid state drive (whichever applicable).
8. Install the memory modules.
9. Install the base cover.
10. Install the SD card.
11. Follow the procedure in After working inside your computer.
Removing the eDP cable (with aluminum chassis)
CAUTION: The information in this section is intended for authorized service technicians only.
NOTE: This procedure is applicable for systems shipped with aluminum chassis only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the memory modules.
5. Remove the M.2 2230 solid state drive or M.2 2280 solid state drive (whichever applicable).
6. Remove the wireless card.
7. Remove the aluminum display assembly .
About this task
The following image indicates the location of the eDP cable (in a system shipped with an aluminum chassis) and provides a visual
representation of the removal procedure.
116
Removing and installing Field Replaceable Units (FRUs)
