Next steps
1. Install the eDP cable.
2. Install the display panel.
3. Install the hinges.
4. Install the display bezel.
5. Install the hinge caps.
6. Install the aluminum display assembly.
7. Install the wireless card.
8. Install the base cover.
9. Install the SD card.
10. Follow the procedure in After working inside your computer.
Display cover and antenna assembly
Replacement of the display cover and antenna assembly
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
NOTE: This procedure is applicable for systems shipped with a plastic chassis only.
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the wireless card.
5. Remove the plastic display assembly or aluminum display assembly (whichever applicable).
6. Remove the hinge caps.
7. Remove the display bezel.
8. Remove the hinges.
9. Remove the display panel.
10. Remove the eDP cable (with plastic chassis) or eDP cable (with aluminum chassis) (whichever applicable).
NOTE:
The display cover and antenna assembly cannot be further disassembled. If the WLAN antennas are malfunctioning
and needs replacement, replace the entire display cover and antenna assembly.
About this task
The following image indicates the location of the display cover and antenna assembly and provides a visual representation of the
removal procedure.
Display cover (plastic chassis)
124
Removing and installing Field Replaceable Units (FRUs)
