6. Install the SD card.
7. Follow the procedure in After working inside your computer.
Camera assembly
Removing the camera module (with plastic chassis)
CAUTION: The information in this section is intended for authorized service technicians only.
NOTE: This procedure is applicable for systems shipped with a plastic chassis only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the wireless card.
5. Remove the plastic display assembly.
6. Remove the hinge caps.
7. Remove the display bezel.
8. Remove the hinges.
9. Remove the display panel.
10. Remove the eDP cable.
About this task
The following images indicate the location of the camera module (in a system shipped with plastic chassis) and provide a visual
representation of the removal procedure.
