Table 17. Power adapter specifications (continued)
Description Option one Option two Option three
Depth
128 mm (5.03 in.) 154.70 mm (6.09 in.) 143 mm (5.62 in.)
Input voltage
100 VAC–240 VAC 100 VAC–240 VAC 100 VAC–240 VAC
Input frequency
50 Hz–60 Hz 50 Hz–60 Hz 50 Hz–60 Hz
Input current (maximum)
1.50 A 1.80 A 1.80 A
Output current (continuous)
4.62 A (continuous) 6.67 A (continuous) 6.50 A (continuous)
Rated output voltage
19.5 VDC 19.5 VDC 20 VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to
104°F)
0°C to 40°C (32°F to 104°F)
Storage
-40°C to 70°C (-40°F to
158°F)
-40°C to 70°C (-40°F to
158°F)
-40°C to 70°C (-40°F to
158°F)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
Battery
The following table lists the battery specifications of your Inspiron 16 Plus 7630.
Table 18. Battery specifications
Description Values
Battery type
6-cell, 86 Wh polymer
Battery voltage
11.40 VDC
Battery weight (maximum)
0.34 kg (0.75 lb)
Battery dimensions:
Height
7.56 mm (0.30 in.)
Width
294.90 mm (11.31 in.)
Depth
77.50 (3.05 in.)
Temperature range:
Operating
● Charge: 0°C to 45°C (32°F to 113°F)
● Discharge: 0°C to 70°C (32°F to 158°F)
Storage
-20°C to 60°C (-4°F to 140°F)
Battery operating time Varies depending on operating conditions and can significantly
reduce under certain power-intensive conditions.
Battery charging time (approximate)
NOTE: Control the charging time, duration, start and
end time, and so on using the Dell Power Manager
● 0°C to 15°C: 4 hours
● 16°C to 50°C: 3 hours
(when the system is turned off)
Specifications of Inspiron 16 Plus 7630 25
