System-diagnostic lights
This section lists the system-diagnostic lights of your Inspiron 16 Plus 7630.
Table 42. System-diagnostic lights
Blinking pattern
Problem description Suggested resolutionAmber White
1 1 TPM detection failure Replace the system board.
1 2 Unrecoverable SPI flash
failure
Replace the system board.
1 3 Short in hinge cable tripped
OCP1
Check if the display-assembly
cable (EDP) is seated properly
or pinched at the hinges.
If problem persists, replace
either display-assembly cable
(EDP) or display assembly
(LCD).
1 4 Short in hinge cable tripped
OCP2
Check if the display-assembly
cable (EDP) is seated properly
or pinched at the hinges.
If problem persists, replace
either display-assembly cable
(EDP) or display assembly
(LCD).
1 5 EC unable to program i-Fuse Replace the system board.
1 6 EC internal failure Disconnect all power source
(AC, battery, coin cell) and
drain flea power by pressing
and holding down power
button for 3~5 seconds.
1 7 Non-RPMC Flash on boot
guard fused system
2 1 Processor failure Replace the processor. If the
processor is onboard, replace
the system board.
2 2 System board: BIOS or ROM
(Read-Only Memory) failure
Replace the system board.
2 3 No memory or RAM
(Random-Access Memory)
detected
Confirm that the memory
module is installed properly. If
problem persists, replace the
memory module.
2 4 Memory or RAM (Random-
Access Memory) failure
Confirm that the memory
module is installed properly. If
problem persists, replace the
memory module.
2 5 Invalid memory module
installed
Confirm that the memory
module is installed properly. If
problem persists, replace the
memory module.
2 6 System-board or chipset error Replace the system board.
2 7 Display failure - SBIOS
message
Replace display-assembly
cable (EDP) if possible,
Troubleshooting 97
