NOTE: Your computer may have up to two memory modules installed. Repeat steps 1 to 3 if there is a second memory
module installed.
Installing the memory
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image(s) indicate the location of the memory and provides a visual representation of the installation procedure.
Steps
1. Lift the Mylar to access the memory-module slot.
2. Align the notch on the memory module with the tab on the memory-module slot on the system board.
3. Slide the memory module into the memory-module slot on the system board.
4. Press down on the memory module till the securing clips click, locking the memory module in place.
32
Removing and installing components
