Dell W32C User Manual

Power supply connector
The following table lists the Power supply connector specifications of your OptiPlex All-in-One 7410.
Table 17. Power supply connector
160 W internal power supply unit (PSU), 80 Plus Bronze
● One 8-pin connector for processor
● One 6-pin connector for system board
● One 6-pin connector for control signal
● One 2-pin connector for LED
Display
The following table lists the display specifications of your OptiPlex All-in-One 7410.
Table 18. Display specifications
Description Option one Option two
Display type
Full High Definition (FHD), ComfortView
Plus
Full High Definition (FHD), ComfortView
Plus
Touch options
No Touch support, with 10 touch points
Display-panel technology
In-Plane Switching (IPS) In-Plane Switching (IPS)
Display-panel dimensions (active area):
Height
296.46 mm (11.67 in.) 296.46 mm (11.67 in.)
Width
527.04 mm (20.75 in.) 527.04 mm (20.75 in.)
Diagonal
604.70 mm (23.81 in.) 604.70 mm (23.81 in.)
Display-panel native resolution
1920 x 1080 1920 x 1080
Luminance (typical)
250 nits 300 nits
Megapixels
2.07 2.07
Color gamut
99% (sRGB) 99% (sRGB)
Pixels Per Inch (PPI)
92 92
Contrast ratio (min.)
● 700:1, minimum
● 1000:1, typical
● 700:1, minimum
● 1000:1, typical
Response time (max.)
● 25 ms, minimum
● 14 ms, typical
● 20 ms, minimum
● 14 ms, typical
Refresh rate
60 Hz 60 Hz
Horizontal view angle
● +/- 85 degrees, minimum
● +/- 89 degrees, typical
● +/- 85 degrees, minimum
● +/- 89 degrees, typical
Vertical view angle
● +/- 85 degrees, minimum
● +/- 89 degrees, typical
● +/- 85 degrees, minimum
● +/- 89 degrees, typical
Pixel pitch
0.27 mm 0.27 mm
30 Specifications of OptiPlex All-in-One 7410
