● Phillips screwdriver #1

● Plastic scribe

Screw list

NOTE: When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and

then place them in a screw storage box. This is to ensure that the correct number of screws and correct screw type is

restored when the component is replaced.

NOTE: Some computers have magnetic surfaces. Ensure that the screws are not left attached to such surfaces when

replacing a component.

NOTE: Screw color may vary with the configuration ordered.

NOTE: This screw list information is for computers shipped with a High Performance processor.

Table 23. Screw list for computers with High Performance processors

Component Screw type Quantity

System-board shield M3x5 6

Wireless card M2x3.5 1

M.2 2230/2280 solid-state drive in M.2 slot 0 M2x3.5 1

M.2 2230/2280 solid-state drive in M.2 slot 1 M2x3.5 1

I/O cover M3x5 2

Bottom cover M3x5 3

Retractable-camera assembly M3x5 4

Fan M3x5 3

I/O bracket M3x5 2

Heat sink Captive 5

Power-supply unit M3x5 3

Power-supply connector cable bracket M3x5 2

Power-supply fan M3x5 2

System board M3x5 7

M3x12 1

Power-button and I/O board shield M3x5 3

Power-button and I/O board M3x5 2

Audio board shield M3x5 3

Audio board M3x5 2

NOTE: This screw list information is for computers shipped with a Energy Efficient processor.

Table 24. Screw list for computers with Energy Efficient Processors

Component Screw type Quantity

System-board shield M3x5 6

Wireless card M2x3.5 1

Hard-drive bracket M3x5 1

Working inside your computer 37
