2 Analog Output Module DVP02DA-E2/DVP04DA-E2
2.6.3 Explanation on Special Registers D9900~D9999
When ES2 MPU is connected with modules, registers D9900~D9999 will be reserved for storing values from
modules. You can apply MOV instruction to operate values in D9900~D9999.
When ES2 MPU is connected with DVP04AD-E2, the configuration of special registers is as below:
Module#0 Module #1 Module #2 Module #3 Module #4 Module #5 Module #6 Module #7 Description
D1320 D1321 D1322 D1323 D1324 D1325 D1326 D1327 Model Code
D9900 D9910 D9920 D9930 D9940 D9950 D9960 D9970 CH1 output
value
D9901 D9911 D9921 D9931 D9941 D9951 D9961 D9971 CH2 output
value
D9902 D9912 D9922 D9932 D9942 D9952 D9962 D9972 CH3 output
value
D9903 D9913 D9923 D9933 D9943 D9953 D9963 D9973 CH4 output
value
1. Example
Ladder diagram: Explanation:
Set CH1 output value of Module#0 as
K10000
Set CH2 output value of Module#1 as D2
M1000
K30000 D9922
K10000
MOV
D2
MOV
MOV
D9900
D9911
Set CH3 output value of Module#2 as
K30000
2.7 D/A Conversion Curve
You can adjust the conversion curves according to the actual needs by changing the Offset value (CR#28 ~ CR#31)
and Gain value (CR#34 ~ CR#37).
Gain (in DVP02/04DA-E2): The corresponding voltage (current) output value when the digital input value = 16,000.
Offset (in DVP02/04DA-E2): The corresponding voltage (current) output value when the digital input value = 0.
 For voltage output Mode 0: 0.3125mV = 20V/64,000
Equation:


















32000
)(10
16000
V
Offset
OffsetGainX
VY
Y= Voltage output, X= Digital input
 For current output Mode 1: 0.625A = 20mA/32,000
Equation:


















32000
)(20
16000
mA
Offset
OffsetGainX
mAY
Y= Current output, X= Digital input
 For current output Mode 2: 0.5A = 16mA/32,000
Adopt the equation of current output mode 1, substitute Gain for 19,200(12mA) and Offset for 6,400(4mA)
Equation:


















32000
)(20
6400
16000
640019200 mAX
mAY
Y= Current output, X= Digital input
