3 Mixed Analog Input/Output Module DVP06XA-E2
3.6.2 Explanation of CR
CR#0: Model name
[Explanation]
1. DVP06XA-E2 model code = H’00C4.
2. You can read the model name in the program to see of the extension module exists.
CR#1: Firmware version
[Explanation]
Display the current firmware version in hex, e.g. version V1.00 is indicated as H’0100.
CR#2, 3, 4, 5: CH1 ~ CH4 input mode setting
[Explanation]
Set the working mode of the input channels of the analog input/output module. There are 8 modes for
each channel which can be set up separately.
When you set CH1 as mode 1 (H’0001) CR#2 has to be set as H’0001. The default setting = H’0000. Take
CH1 as example:
Mode 0 (H’0000): Voltage input (-10V ~ +10V).
Mode 1 (H’0001): Voltage input (-5V ~ +5V).
Mode 2 (H’0002): Voltage input (0V ~ +10V).
Mode 3 (H’0003): Voltage input (0V ~ +5V).
Mode 4 (H’0004): Current input (-20mA ~ +20mA).
Mode 5 (H’0005): Current input (0mA ~ +20mA).
Mode 6 (H’0006): Current input (+4mA ~ +20mA).
Mode -1(H’FFFF): Channel 1 unavailable..
CR#6, 7: CH5 ~ CH6 output mode setting
[Explanation]
Set the working mode of the output channels of the analog input/output module. There are 4 modes for
each channel which can be set up separately.
When you sett CH5 as mode 1 (H’0001) CR#6 has to be set as H’0001. The default setting = H’0000. Take
CH5 as example:
Mode 0 (H’0000): Voltage output (-10V ~ +10V).
Mode 1 (H’0001): Current output (0mA ~ 20mA).
Mode 2 (H’0002): Current output (4mA ~ 20mA).
Mode close (H’FFFF): Channel 5 unavailable.
CR#8, 9, 10, 11: CH1 ~ CH4 average times
[Explanation]
1. The average times of the signals at CH1 ~ CH4.
2. Setup range for DVP06XA-E2: K1 ~ K100. Default = K10. If the set value exceeds K100, the value
will be set as K100; if the set value is lower than K1, the set value will be set as K1
CR#12, 13, 14, 15: Average input values at CH1 ~ CH4
[Explanation]
The average value of the signals at CH1 ~ CH4 is calculated according to the average times set in CR#8
~ CR#11. For example, if the set value in CR#8 ~ CR#11 is K20, the content in CR#12 ~ CR#15 will be
the average of the most recent 20 signals in CH1 ~ CH4
CR#20, 21, 22, 23: Present input value at CH1 ~ CH4
[Explanation]
Display the present value of input signals at CH1 ~ CH4.
CR#28, 29, 30, 31: Adjusted Offset value of CH1 ~ CH4
[Explanation]
1. Set the adjusted Offset value of CH1 ~ CH4, which represents the voltage (current) input value
corresponds to digital value 0.
