Delta M60U User Manual

①
⑨
⑤
④
⑧
⑦ ⑦⑩ ⑥⑥
NO Location Screw torque
11
Mounting bracket 40.0 lbf-in (4.5N•m)
10 Wiring box fan 7.00 lbf-in (0.8N•m)
12
Communication cover 7.00 lbf-in (0.8N•m)
9
SPD board 14.6 lbf-in (1.6N•m)
8
Ground of SPD board 6.90 lbf-in (0.8N•m)
7
Grounding point 69.4 lbf-in (7.8N•m)
6
5
AC grounding terminal 49.5 lbf-in (5.6N•m)
2
Mounting screw of grounding bar 22.0 lbf-in (2.5N•m)
Grounding bar 26.0 lbf-in (3.0N•m)
1 AC switch 31.0 lbf-in (3.5N•m)
Conductor cross-section
-
-
-
-
-
-
1~2/0 AWG (35~50mm²)
-
6~4 AWG (14~22mm²)
14 Insulator cover 7.00 lbf-in (0.8N•m) -
13 MC4 wire
- 12~10AWG (4~6mm²)
1~2/0 AWG (35~50mm²)
3 Communication port - 20 AWG (0.5mm²)
Wiring box cover 21.0 lbf-in (2.37N•m)
- 4
Appendix C-5: Assembly Note for 122 model
⑪⑬
⑭
122 Model
WB
②
③
⑪
⑫ ⑫
127
Appendix C: Assembly Note
