The chapter contains instructions for
(1) Mechanical installation
(2) Electrical Installation
(3) Communication setup
Figure 3-1 shows the hoisting hook instruction.
Figure 3-2 provides the mechanical dimensions of the inverter.
3 Installation
- In some locations, mounting the inverter in direct sunlight may cause the inverter
to enter a thermal derating mode. To eliminate this concern, a shade structure
over the inverter chassis may be necessary.
CAUTION !
WARNING !
- Do not install the unit near or on flammable surfaces.
- Inverter must be mounted securely to a solid / smooth surface.
This unit is designed to be wall-mounted per Section 3.1.1 or Tilt Mounted per
Section 3.1.2.
Refer to Figures 3-3 through Figures 3-15.
1. Ensure the surface to which the unit is to be mounted is sufficiently strong
enough to carry the weight.
2. Orient the wall bracket (Figure 3-4, Figure 3-5 or Figure 3-7, Figure 3-8)
horizontally (perpendicular to the floor), with the large plate at the bottom,
and mark required mounting hole locations per Figure 3-6 or Figure 3-9.
3. Secure the mounting bracket on the wall with at least 8 5/16” (M8) screws.
4. Hang the inverter on the wall mounting bracket.
5.
Secure the inverter by inserting and tightening four screws (item 6, Figure 2-1)
as shown in Figure 3-15.
3.1 Mechanical Installation
3.1.1 Vertical wall mount
24
Installation
