The M80/60U transformerless 3Ø PV inverters are designed to enable the
highest levels of efficiency and provide longest operating life by use of
state-of-the-art high frequency and low EMI switchmode technology.
They meet the design requirements of UL1741/SA, IEEE1547, IEEE1547.1,
IEEE1547.A and OSHA, and is suitable for indoor or outdoor use.
The user manual is valid for the following device types:
For 121 models there are two versions, MxxU_121 with RSD (Rapid Shutdown
Device) and MxxU_121 without RSD, please refer Figure 2-5 for details.
This user manual must be followed during installation, operation, and maintenance.
The M80/60 Series each have three models as shown in Figure 2-2. Delta
reserves the right to make modifications to the content and technical data in this
user manual without prior notice.
• M80U
_121
• M60U_121
• M80U_120
• M60U_120
• M80U_122
• M60U_122
2 Introduction
2.1 Valid Model
- This product utilizes a transformerless design, and is not provisioned with an
isolation transformer, and therefore has no galvanic isolation between the DC
and AC sides.
PV array circuits connected must be floating with respect to ground, i.e., must
not be referenced (bonded) to ground.
If grounded PV arrays are connected to the inverter, the inverter will not connect
to the grid and the error message INSULATION (E34) will appear on the display.
- It is prohibited to connect terminals L1, L2, or L3 to ground.
The inverter installation must be performed by an authorized electrician in accordance
with the the National Electrical Code® ANSI/NFPA 70 or the Canadian Electrical Code®
CSA C22.1 and/or other prevailing local codes, as well as OSHA requirements.
