After completion of First Start and inverter is in normal operation, the LCD will
display the homepage screen as shown in Figure 4-3. The user can view
information to include output power, inverter status, E-today, date and time.
Pressing "any" key in home page mode will open the main menu. To return to
Home Page screen, press EXIT at main menu or wait 5 minutes without any
key operation, the display will return to homepage.
4.2.1 Home Page
Table 4-3 contains is a listing of all inverter functions that can be adjusted by
users (U) and installers (I) via the LCD panel, and the associated manual
subsection where a description of the operation of each is found.
4.3 Main Menu
Figure 4-3: Home Page screen
Table 4-3: Inverter Functions
21 Jan. 2016 16:30
Status: :
Power:
E-Today:
42000 W
147 kWh
On Grid
Inverter Status
Output Power
Today Energy
Day -Time
Function Para
Power Meter 4.3.1
Energy Log
String Current Mon
4.3.2
Event Log
4.3.3
Information
4.3.4
General Settings
4.3.5
Inverter ID
4.3.7
Insulation
4.3.7.1
4.3.7.2
Grid Code 4.3.7.3
Install Settings
4.3.6
Access
U,I
U,I
U,I
U,I
U,I
I
I
I
I
U,I
I
I
I
I
I
I
I
I
I
Function Para
Grid Settings 4.3.7.4
4.3.7.5
PID
4.3.7.6
RCMU
4.3.7.7
AC Connection
4.3.7.9
Emergency Power-Off
4.3.7.8
AFCI
4.3.7.11
Grid code confirm
Active / Reactive power
4.3.8
Anti-Islanding
4.3.7.10
Access
67
Commissioning
To Next Page
