Chapter 4 Parameters  VFD-EL-W
4-60
Group 5: Multi-Step Speed Parameters
 You can set this parameter during operation.
05.00
1st Step Speed Frequency Unit: 0.01
05.01
2nd Step Speed Frequency Unit: 0.01
05.02
3rd Step Speed Frequency Unit: 0.01
05.03
4th Step Speed Frequency Unit: 0.01
05.04
5th Step Speed Frequency Unit: 0.01
05.05
6th Step Speed Frequency Unit: 0.01
05.06
7th Step Speed Frequency Unit: 0.01
Settings 0.00–400.00Hz Default: 0.00
 The multi-function input terminals (refer to Pr.04.06–Pr.04.08) select one of the AC motor drive multi-step
speeds (maximum of seven speeds). The speeds (frequencies) are determined by Pr.05.00–Pr.05.06 as
shown in the following table.
Parameter
Multi-step speed
command 1
Multi-step speed
command 2
Multi-step speed
command 3
Master
frequency
Master speed
OFF OFF OFF
1
st
speed 05.00 ON OFF OFF
2
nd
speed 05.01 OFF ON OFF
3
rd
speed 05.02 ON ON OFF
4
th
speed 05.03 OFF OFF ON
5
th
speed 05.04 ON OFF ON
6
th
speed 05.05 OFF ON ON
7
th
speed 05.06 ON ON ON
