Chapter 4 Parameters
VFD-EL-W
4-4
Group 1 Basic Parameters
Parameter
Function Setting Default
Customer
01.00 Maximum Output Frequency (Fmax) 50.00–400.0 Hz 60.00
01.01 Motor Rated Frequency (Fbase) 0.10–400.0 Hz 60.00
01.02 Motor Rated Voltage (Vbase)
230V series: 0.1–255.0 V 220.0
460V series: 0.1–510.0 V 440.0
01.03 Mid-Point Frequency (Fmid) 0.10–400.0 Hz 1.50
01.04 Mid-Point Voltage (Vmid)
230V series: 0.1–255.0 V 10.0
460V series: 0.1–510.0 V 20.0
01.05 Minimum Output Frequency (Fmin) 0.10–400.00 Hz 1.50
01.06 Minimum Output Voltage (Vmin)
230V series: 0.1–255.0 V 10.0
460V series: 0.1–510.0 V 20.0
01.07 Output Frequency Upper Limit 0.1–120.0% 110.0
01.08 Output Frequency Lower Limit 0.0–100.0 % 0.0
01.09
Acceleration Time 1 (Taccel 1) 0.1–600.0 / 0.01–600.00 sec. 10.0
01.10
Deceleration Time 1 (Tdecel 1) 0.1–600.0 / 0.01–600.00 sec. 10.0
01.11
Acceleration Time 2 (Taccel 2) 0.1–600.0 / 0.01–600.00 sec. 10.0
01.12
Deceleration Time 2 (Tdecel 2) 0.1–600.0 / 0.01–600.00 sec. 10.0
01.13
Jog Acceleration Time 0.1–600.0 / 0.01–600.00 sec. 1.0
01.14
Jog Deceleration Time 0.1–600.0 / 0.01–600.00 sec. 1.0
01.15
Jog Frequency 0.10–400.0 Hz 6.00
01.16
Auto-Acceleration and
Auto-Deceleration
0: Linear Acceleration and linear
deceleration
0
1: Auto-acceleration and linear
deceleration
2: Linear acceleration and auto-
deceleration
3: Auto-acceleration and auto-
deceleration (Set by load)
4: Auto-acceleration and auto-
deceleration (set by Acceleration
/ Deceleration Time setting)
01.17 Acceleration S-Curve
0.0 (S-curve disabled)
0.1–10.0 / 0.01–10.00
[S-curve enabled (10.0/10.00 is the
smoothest)]
0.0 / 0.00
01.18 Deceleration S-Curve
01.19 Acceleration / Deceleration Time Unit
0: Unit: 0.1 sec.
0
1: Unit: 0.01 sec.
01.20
Simple Positioning Stop Frequency 0
0.00–400.0 Hz
0.00
01.21
Simple Positioning Stop Frequency 1 5.00
01.22
Simple Positioning Stop Frequency 2 10.00
01.23
Simple Positioning Stop Frequency 3 20.00
01.24
Simple Positioning Stop Frequency 4 30.00
