A-1
Appendix A Specifications
A-1. 230V 1φ Series
A-2. 460V 3φ Series
A-3. General Specifications
A-4. Environment for Operation, Storage and
Transportation
A-5. Operation Temperature and Derating Curve of
Ambient Temperature
1. VFD-EL-W has two types of packaging: Individual Package [suffixed with (-1) at the end of the model
name] and 12 pcs/carton.
2. The electrical specifications are the same for either packaging.
3. The VFD-EL-W Series include the 230V and 460V models. The 230V model is one-phase; the 460V
model is three-phase. Refer to following specifications for details.
