Chapter 4 Parameters
VFD-EL-W
4-6
Group 2 Operation Method Parameters
Parameter
Function Setting Default
Customer
02.00
First Master Frequency
Command Source
0: Digital keypad UP/DOWN keys or Multi-
function Inputs UP/DOWN.
1: 0–10 V from AVI
2: 4–20 mA from ACI
3: RS-485 (RJ45) communication
4: Digital keypad potentiometer
0
02.01
First Operation Command
Source
0: Digital keypad
0
1: External terminals. Keypad STOP/RESET
enabled.
2: External terminals. Keypad STOP/RESET
disabled.
3: RS-485 communication. Keypad
STOP/RESET enabled.
4: RS-485 communication. Keypad
STOP/RESET disabled.
02.02 Stop Method
0: STOP: ramp to stop; E.F.: coast to stop
0
1: STOP: coast to stop; E.F.: coast to stop
2: STOP: ramp to stop; E.F.: ramp to stop
3: STOP: coast to stop; E.F.: ramp to stop
4: Simple Positioning Stop; E.F.:coast to stop
02.03
PWM Carrier Frequency
Selection
2–12 kHz 8
02.04 Motor Direction Control
0: Forward/reverse operation enabled
0
1: Reverse operation disabled
2: Forward operation disabled
02.05
Power-On Command and Run
Command Source Modifies
the Drive Operating Control
0: Start running when power is on.
1: Do not run when power is on
2:
When the source of the command changes,
the drive’s operation remains the same.
3:
When the source of the command changes,
the drive’s operation follows the new
command.
4: The
motor drive can start to run at power on
or after reset.
command is a two-
wire external terminal, the
operating command changes as
terminal’s status changes.
1
02.06 Loss of ACI Signal (4–20 mA)
0: Decelerate to 0 Hz
0
1: Coast to stop and display “AErr”
2: Continue the operation according to the last
frequency command
3: Continue the operation according to the
setting at Pr.02.11.
02.07 Up/Down Mode
0: Digital keypad up/down keys mode
0
1: Based on Accel./ Decel. time
2: Constant speed (according to Pr.02.08)
3: Pulse input unit (according to Pr.02.08)
