Delta VFD-EL-W Series User Manual

Chapter 1 Introduction  VFD-EL-W
1-6
Remove the control board cover
As shown in Step 1 below, gently press the control
board cover. Then,
as shown in Step 2, pull it down slowly to remove it.
Step 1
Step2
Remove cooling fan:
To remove the cooling fan of Frame B, gently release the
clips on both sides of the cooling fan.
