Appendix B Accessories_VFD-B Series
Revision 10/2005, BE13, SW V4.08 B-7
B.2 AMD - EMI Filter Cross Reference
AC Drives Model Number FootPrint
VFD007B21A, VFD015B21A RF015B21AA Y
VFD022B21A RF022B21BA Y
VFD007B43A, VFD015B43A, VFD022B43B RF022B43AA Y
VFD037B43A RF037B43BA Y
VFD055B43A, VFD075B43A, VFD110B43A RF110B43CA Y
VFD007B23A, VFD015B23A 10TDT1W4C
N
VFD022B23A, VFD037B23A 26TDT1W4C
N
VFD055B23A, VFD075B23A, VFD150B43A, VFD185B43A 50TDS4W4C N
VFD110B23A, VFD150B23A, VFD220B43A, VFD300B43A,
VFD370B43A
100TDS84C N
VFD550B43A, VFD550B43C, VFD750B43A, VFD750B43C 200TDDS84C N
VFD185B23A, VFD220B23A, VFD300B23A, VFD450B43A 150TDS84C N
VFD370B23A 180TDS84C N
VFD022B23B 20TDT1W4D N
VFD022B21B 35DRT1W3C N
VFD037B43B, VFD037B23B 26TDT1W4B4 N
Installation
All electrical equipment, including AC motor drives, will generate high-frequency/low-frequency noise and will
interfere with peripheral equipment by radiation or conduction when in operation. By using an EMI filter with
correct installation, much interference can be eliminated. It is recommended to use DELTA EMI filter to have
the best interference elimination performance.
