Appendix B Accessories_VFD-B Series
Revision 10/2005, BE13, SW V4.08 B-11
B.2.1 Dimensions
Dimensions are in millimeter and (inch)
Order P/N: RF015B21AA / RF022B43AA
239
(9.4)
118
90
(3.54)
28
(1.1)
50
(1.97)
226
(8.9)
5.5
(3.37)
226
(8.9)
16
(0.63)
24
(0.94)
