Chapter 5 Parameters_VFD-B Series
5-24
Revision 10/2005, BE13, SW V4.08
5.3 Description of Parameter Settings
Group 0: User Parameters a: This parameter can be set during operation.
00 - 00
Identity Code of the AC motor drive
Settings Read Only Factory setting: ##
00 - 01
Rated Current Display of the AC motor drive
Settings Read Only Factory setting: #.#
Pr. 00-00 displays the identity code of the AC motor drive. The capacity, rated current, rated voltage and the
max. carrier frequency relate to the identity code. Users can use the following table to check how the rated
current, rated voltage and max. carrier frequency of the AC motor drive correspond to the identity code.
Pr.00-01 displays the rated current of the AC motor drive. By reading this parameter the user can check if the
AC motor drive is correct.
230V Series
kW 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37
HP 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30 40 50
Pr.00-00 04 06 08 10 12 14 16 18 20 22 24 26
Rated Output
Current (A)
5.0 7.0 11 17 25 33 49 65 75 90 120 146
Max. Carrier
Frequency
15kHz 9 kHz
460V Series
kW 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
HP 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30 40 50 60 75 100
Pr.00-00 05 07 09 11 13 15 17 19 21 23 25 27 29 31 33
Rated Output
Current (A)
2.7 4.2 5.5 8.5 13 18 24 32 38 45 60 73 91 110 150
Max. Carrier
Frequency
15 kHz 9 kHz 6 kHz
575V Series
kW 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
HP 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30 40 50 60 75 100
Pr.00-00 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114
Rated Output
Current (A)
1.7 3.5 4.5 7.5 10 13.5 19 22 27 34 41 52 62 80 100
Max. Carrier
Frequency
10 kHz 8 kHz 6 kHz
