Delta VFD185B43A User Manual

Chapter 5 Parameters_VFD-B Series
5-34
Revision 10/2005, BE13, SW V4.08
01-00
01-09
01-11
01-18
01-20
01-10 01-12
01-19 01-21
Frequency
Time
Accel. Time
Decel. Time
The definition of
Accel./Decel. Time
Max. output
Frequency
setting
operation
frequency
Min. output
frequency
01-05
Resulting
Resulting
Accel. Time
Decel. Time
Resulting Accel./Decel. Time
0 Hz
01 - 13
aJog Acceleration Time Unit: 0.1
Settings 0.1 to 3600.0 sec Factory Setting: 1.0
01 - 22
aJog Deceleration Time Unit: 0.1
Settings 0.1 to 3600.0 sec Factory Setting: 1.0
01 - 14
aJog Frequency Unit: 0.1
Settings 0.10 to 400.00Hz Factory Setting: 1.0
Both external terminal JOG and key “JOG” on the keypad can be used. When the Jog command is “ON”, the
AC motor drive will accelerate from Minimum Output Frequency (Pr.01-05) to Jog Frequency (Pr.01-14).
When the Jog command is “OFF”, the AC motor drive will decelerate from Jog Frequency to zero. The used
Accel/Decel time is set by the Jog Accel/Decel time (Pr.01-13, Pr.01-22).
Before using the JOG command, the drive must be stopped first. And during Jog operation, other operation
commands cannot be accepted, except command via the FORWARD, REVERSE and STOP keys on the
digital keypad.
