Chapter 5 Parameters_VFD-B Series
5-4
Revision 10/2005, BE13, SW V4.08
Parameter Explanation Settings
Factory
Setting
Customer
a01-14 Jog Frequency 0.10 Hz to 400.00 Hz 6.00
00: Linear Accel/Decel
01: Auto Accel, Linear Decel
02: Linear Accel, Auto Decel
03: Auto Accel/Decel (Set by load)
a01-15
Auto acceleration / deceleration
(refer to Accel/Decel time setting)
04: Auto Accel/Decel (set by Accel/Decel
Time setting)
00
01-16 Acceleration S-Curve 00 to 07 00
01-17 Deceleration S-Curve 00 to 07 00
a01-18 Accel Time 3 0.01 to 3600.0 sec 10.0
a01-19 Decel Time 3 0.01 to 3600.0 sec 10.0
a01-20 Accel Time 4 0.01 to 3600.0 sec 10.0
a01-21 Decel Time 4 0.01 to 3600.0 sec 10.0
01-18 ~ 01-21: Factory setting for models of 30hp (22kW) and above is 60sec.
a01-22 Jog Deceleration Time 0.1 to 3600.0 sec 1.0
00: Unit: 1 sec
01: Unit: 0.1 sec
01-23 Accel/Decel Time Unit
02: Unit: 0.01 sec
01
Group 2 Operation Method Parameters
Parameter Explanation Settings
Factory
Setting
Customer
00: Digital keypad (PU01) UP/DOWN keys
or Multi-function Inputs UP/DOWN. Last
used frequency saved.
01: 0 to +10V from AVI
02: 4 to 20mA from ACI
03: -10 to +10Vdc from AUI
04: RS-485 serial communication (RJ-11).
Last used frequency saved.
05: RS-485 serial communication (RJ-11).
Last used frequency not saved.
a02-00
Source of First Master Frequency
Command
06: Combined use of master and auxiliary
frequency command
(See Pr. 02-10 to 02-12)
00
00: Digital keypad (PU01)
a02-01
Source of First Operation
Command
01: External terminals. Keypad
STOP/RESET enabled.
00
