SIRIUS
®
TECHNICAL REFERENCE MANUAL
5.23. Analog out option
The analog output option adds 8 analog output channels (BNC connectors) to the SIRIUS® slices and
supports 4 different operation modes:
● Standalone digital signal conditioner
● Function Generator (Modal/Shaker control)
● File replay to analog
● Channel Output
Important
For SIRIUS Function Generator option a software licence is required!
Important
● The Analog output Function generator option is only available with USB connection.
● The Analog out Signal conditioning option in HD - High Density SIRIUS slice is possible for
the first 8 channels only.
● The Multi modules have the analog out channels per default on the front side
connectors. When you order a Multi module with additional analog out OPTION, the front
side analog out will NOT be connected – only the analog out of the rear BNC connectors.
SIRIUS
®
V20-1 253 / 336
