TECHNICAL REFERENCE MANUAL
12. Documentation version history
● The NEW SIRIUS manual - Reworked and revised version
12.1. Previous versions history
● New orange logo and style
● non-isolated is now called differential
● Added CHG, LV, HD-ACC, HS-CHG, HS-HV, HS-LV, HS-STG
● Replaced STGM with STGMv2, HV with HVv2 and STG with STGv2
● Added SIRIUS-R2D, SIRIUS-R8D, updated SIRIUS-R8
● Corrected specs
○ HS-ACC (sampling rate)
○ MULTI: Bridge Ranges
○ HD-LV: ADC type, Over-voltage Protection
○ HD-STGS: ADC type, Bridge Ranges, Exc. Voltage, removed
Counters
○ Analogue-out: bandwidth
○ Expanded general specifications
● SBOXx-GPS: removed 1Hz: all others are optional
● Added power connector pins and mating connectors
● Added HD-ACC module
● Added HD-LV BNC
● Updated Specs: LV2 , Multi, STGv2, STGMv2, HS-ACC, HS-CHG,
HS-STG
● Added EtherCAT® information
● Updated image of EtherCAT single slice version in chapter 4.2.2: now
you see the USB connector
● Updated pin‐out images of BNC connectors
● SIRIUS® is now a registered trademark
● Added chapter 6 Measurement including Anti-Aliasing
● Added chapter for Firmware-upgrade
● ACC+: corrected Sensor Supply voltage (was 14V – now 12V)
● Digital Filter (vs. Sample Rate): removed from Specifications tables
and moved to “ADC oversampling chapter” and corrected the
frequency ranges
● MSI-BR-TH are now called MSI-TH
● Chapter “HS-LV DSUB-9”: corrected connectors and wiring diagrams
● CHG and HS-CHG: added missing Input coupling 0.5Hz
