SIRIUS
®
TECHNICAL REFERENCE MANUAL
4.10.7. SIRIUS-R2-HUB/R4-HUB: Front side
SIRIUS-R4-HUB
Name
Description
SYNC
2x 4-pin LEMO male sync connector
GND
Protective Ground banana plug and screw
connector
USB
USB 2.0, USB Mini B
PWR
To switch the System on/off.
IN
Power in 3-pin LEMO male connector
SIRIUS
®
V20-1 83 / 336
