DEWESOFT SIRIUS-SBOXe User Manual

/
SIRIUS
® 
TECHNICAL REFERENCE MANUAL 


4.6. SIRIUS-SBOXwe 
Extremely rugged data logger and powerful data processing computer with IP67 degree of protection              
and wide temperature rating of -40 °C to +50 °C. SBOX waterproof is a perfect companion to the SIRIUS                   
waterproof data acquisition systems. 
4.6.1. SIRIUS-SBOXwe: Specifications 
Computer 
Processor 
Intel® Core™ i7 
2x 1.7 GHz base, 3.3 GHz max 
4 threads 
Memory 
4 GB (optional up to 16 GB) 
Storage 
250 GB mSATA SSD 
Interfaces and options 
USB 
5x USB 2.0 (Push-Pull) 
Ethernet 
2x GLAN (Push-Pull), 1x WLAN (RP-SMA Female Jack) 
EtherCAT® 
1x EtherCAT® 100 Mbps Full Duplex, 8-pin LEMO female 
Video 
DVI-D 
Synchronisation 
1x SIRIUS® SYNC 
GPS (option) 
10 Hz or 100 Hz or 100 Hz + RTK 
GPS display (option) 
External on DSUB-9 connector with remote power on 
Power out 
Switched input supply on 2-pin LEMO female (max. 8 A) 
Power 
Power supply 
9 - 36 V DC 
Power consumption 
Typ. 18 W 
Environmental 
Operating Temperature 
-40 to 50°C 
Storage temperature 
-40 to 80 °C 
Humidity 
5 to 100 % RH 
IP rating 
IP65 / IP67 
Shock 
Shock: SIST EN 60068-2-27:2009 
50 g, 6 ms, half-sine 
100 g, 4 ms, half-sine 
50x pos./neg in each axis 
600x total 
Vibration 
Random: 
Profile breakpoints: 
24 Hz - 0.023 g²/Hz 
60 Hz - 0.28 g²/Hz 
100 Hz - 0.28 g²/Hz 
240 Hz - 0.056 g²/Hz 
2 kHz - 0.056 g²/Hz 
Profile RMS / Peak = 11.5 g / 34.5 g (up to 15 / 45 g with absorbers) 
6 hrs in each axis, 18 hrs total 
Physical 
Dimensions 
282 x 135 x 70 mm 
Weight 
2.55 kg 

