17
IP2251EN
Output
Value of
accessories
Description
RDX
ZENRS
ZENPRS
The control panel is fitted with a housing for modules of the
6ZENRS radio receiver type (433.92MHz).
Can be replaced with a radio receiver module of the ZENPRS
type (868.35MHz).
The operating mode is selected via
→ .
When using slot-in radio boards, remove the RDX module. The
display will show
.
WARNING: the modules must be inserted and removed with the
power supply disconnected.
COM
BIXMR2
COM - This allows the functioning configurations to be saved using
the function
→ .
The saved configurations can be recalled using the function
→ .
COM - The storage module allows the remote controls to be stored.
If the control panel is replaced, the storage module being used
can be inserted in the new control panel.
WARNING: the storage module must be inserted and removed
with the power supply disconnected, and paying attention to
the positioning direction.
BAT
SBU
BAT - Battery-powered operation.
The batteries are kept charged when the power supply is on. If the
power supply is off, the panel is powered by the batteries until the
power is re-establish or until the battery voltage drops below the
safety threshold. The control panel turns off in the last case. Warn-
ing: the batteries must always be connected to the control panel
for charging. Periodically check the efficiency of the batteries.
NOTE: the operating temperature of the rechargeable batteries
is from +5°C to +40°C.
For advanced control of battery-powered operation, refer to the
menu
.
Jumper Description OFF ON
JR1
Display mode selection. Display mode.
Only the values and parame-
ters present can be displayed.
Maintenance mode.
Only the values and parame-
ters present can be displayed
and modified.
Activated maintenance mode
is indicated by the permanent
switching on of the right-hand
point on the display.
10. Jumper setting
