26
IP2251EN
11.5.1 Additional BO level parameters that can be configured (availa-
ble with
→ enabled)
Display Description
Selections
available
C1, C2, C3, C4 - Selection of CH1, CH2, CH3, CH4 function of stored remote control.
NO - No setting selected
1-3 - Opening command
1-4 - Closing command
1-5 - Step-by-step command
P3 - Partial opening command
LG - Command to switch the courtesy light on/off
1-9 - STOP command
If even just one (any) CH key of the remote control is stored, the opening or step-by-
step command is implemented.
NOTE: the
(opening) and (step-by-step) options are available as alterna-
tives, and depend on the selection
→ .
If 2-4 CH keys of a single remote control are stored, the functions matched in the
factory with the CH keys are as follows:
• CH1 = opening/step-by-step command
• CH2 = partial opening command;
• CH3 =courtesy light on/off command
• CH4 = STOP command.
ER - Deletion of a single remote control
→→
2”
ENTER
RO - Radio operations
RO - Radio operations
RK - Menu navigation using remote control keyboard
ON - Enabled
OF - Disabled
With the display turned off, quickly type in the sequence of keys
3
3
2
4
1
from the stored remote control you want to use.
Make sure all the CH keys are stored.
WARNING: during navigation with a remote control keyboard ALL the stored
remote controls are inactive.
4
1 (Enter)
3 (Esc)
2 (∆)
(∆)
To make viewing and adjustment easier (avoiding the need to continuously
press the remote control), press the UP ↑ or DOWN ↓ key once to begin
slowly scrolling through the parameters.
This scrolling movement is faster if the UP ↑ or DOWN ↓ key is pressed twice.
To stop the scrolling, press ENTER.
To confirm your choice of parameter, press ENTER again.
To test any new setting, switch off the display and issue an opening command
using key
3
.
Navigation using a remote control keyboard is automatically disabled after 4
minutes of inactivity or by setting
→ .
