4
IP2251EN
ASSA ABLOY Entrance Systems AB declares that the Ditec LCU30H control panel complies
with the fundamental requisites and other relevant requirements laid down by the following
EC directives:
EMC Directive 2014/30/EU;
Low Voltage Directive 2014/35/EU.
RED Directive 2014/53/EU.
L a n d s k r o n a , 0 9 - 0 3 - 2 0 2 1 M a t t e o F i n o
President B.A. PGA
2. EC Declaration of Conformity
1.1 Safety functions
The Ditec LCU30H control panel has the following safety functions:
- obstacle recognition with force limiting;
The maximum response time of the safety functions is 0.5s. The reaction time to a faulty safety
function is 0.5s.
The safety functions comply with the standards and performance level indicated below:
EN ISO 13849-1:2015 Category 2 PL=c
EN ISO 13849-2:2012
The safety function cannot be bypassed either temporarily or automatically. Fault exclusion
has not been applied.
3. Technical specifications
NOTE: the given operating and performance features can only be guaranteed with the
use of DITEC accessories and safety devices.
3.1 Applications
LCU30H LCU30HJ
Power supply 230V~ 50/60Hz 120V~ 50/60Hz
Power absorption 0,6A 1,2A
Fuse 1,6A 3,15A
Motor output 24V
6A max (X 2)
Power supply to accessories 0-1 24V
0,5A peak / 0,3A continuous
Ambient temperature -20°C - +55°C
Storable radio codes 100 / 200 see RO → MU → 20/10 (paragraph 11.6)
Radio frequency 433,92MHz
Degree of protection of the container IP55
Product size 187 x 261 x 102
Operating cycles Refer to the characteristics of the actuator used.
