User Menu Options
Page 61
Switching outputs on/off
Master and admin users can use Outputs On/Off to switch outputs on or off
as follows:
1. Select Outputs On/Off.
The display shows the first in a list of any outputs allocated for your
use. For example:
The top line shows the address and type of the output. In the above
example, the address is PAN>01 and the type is W (wired). The
output type is displayed for control units that have built-in radio and
wired outputs. The bottom line shows the name of the output (which
may be the same as the address) and whether the output is currently
on or off.
2. Press or to select the output.
3. Press or to switch the output on or off. Outputs operated via
radio may take several seconds to change state.
4. Press repeatedly to exit.
Using the About options
If you are a master or admin user, you can use the About option to find
information about the system you are using. The About menu contains the
following options:
Panel This gives:
The control unit model (e.g. i-on40H+).
The control unit's software (firmware) and
bootloader version number.
The installed languages and their versions.
Whether the control unit is in partitioned or part-
setting mode (if applicable).
Cloud This gives information about the connection to the
SecureConnect.
