OPERATING INSTRUCTIONS | SMART LINE | BOILING PAN
10
DOC.N
O
: ST09184-02 EN | 02-2015
Smart Line boiling pans with dual connection
PNC F. Mod.
Weight
Kg
Total power
kW
Voltage
V / neutral
conductor
Frequency
Hz
Max. phase current
A
232222 + 928091 SM6B300 480 25 / 25 400 V / 3N 50/60 36 / 36
232226 + 928092 SM6V200 400 25 / 14.7 400 V / 3N 50/60 36 / 25
232227 + 928092 SM6V300 480 25 / 27.2 400 V / 3N 50/60 36 / 43
232230 + 928092 SM6P200 400 25 / 15.5 400 V / 3N 50/60 36 / 29
232231 + 928092 SM6P300 500 25 / 28 400 V / 3N 50/60 36 / 47
Smart Line kokgrytor med tillval isvattenkylning
PNC F. Mod.
Weight
Kg
Total power
kW
Voltage
V / neutral
conductor
Frequency
Hz
Max. phase current
A
232223 + 928153 SM6V50 180 15.8 400 V / 3N 50/60 27
232224 + 928154 SM6V100 280 24 400 V / 3N 50/60 39
232225 + 928155 SM6V150 400 31.5 400 V / 3N 50/60 51
232226 + 928156 SM6V200 400 39.7 400 V / 3N 50/60 62
232227 + 928157 SM6V300 480 52.2 400 V / 3N 50/60 80
3. TESTING /
CERTIFICATION
All appliances are tested and certified according
to the relevant standards and approved engineer-
ing rules by internationally recognised testing bod-
ies. This guarantees that all internationally required
quality and safety standards have been met.
Each appliance features the CE marking on its
nameplate. All appliances have passed the test-
ing for protection class IP X5 (water protection). To
ensure continued compliance with this protection
class, all seals must remain in a perfect condition
and all components must be assembled properly
after installation, repairs and maintenance work.
CE- DIRECTIVES
Boiling pans are manufactured
in compliance with directives MD 2006/42/EG
(AFS 2008:3), LVD 2006/95/EG, EMC 2004/108/
EG, PED 97/23/EG (AFS 1994:4). The machine is
regarded as an appliance. The appliance consists of
a CE approved safety valve (Category IV) and a CE
approved pressure vessel (Category II). Procedures
for assessing compliance of the appliance are
drawn up in accordance with Module A. (Standards:
EN13886:2005+A1:2010,EN ISO 12100:2010,
EN 60204-1 A1:2009, EN13445-1-5) and are CE
labelled.
