Press Tilt return .
Close the grid and press Agitator start .
•PressOn/Off . The display goes out.
•Wait5seconds!
•PressOn/Off . Display lights.
If the warning is still lit:
•PressOn/Off to close the pan.
The display goes out.
See Warning! Overheating and contact au-
thorised personnel.
Follow the instructions in the display.
•PressSTOP to stop. or
•PressSTART to return to the program.
•PressOn/Off
The display goes out.
•Turnthemainswitch to position 0.
Wait for approx 1 minute.
•Turnthemainswitch to position 1.
•PressOn/Off . Display lights.
Increase agitator speed or reduce the amount
of food in the pan
Contact authorised personnel.
Contact authorised personnel.
Contact authorised personnel.
Contact authorised personnel.
Contact authorised personnel.
Press STOP to interrupt the manual wa-
ter filling.
Order service by authorized personnel
Reset the emergency stop
Start the COOLING program and stop it after
approximately 20 seconds.
Restart the BOILING program (Only boiling
pans with Ice-water cooling).
Red LED in START flashes. The following
text appears in the display:
TILTING
Xh XXmin XXX°C
ATOR 000rpm
AGITATOR
LID/GRID ON
Buzzer sounds and the following text appears
in the display:
ELEMENT
OVERHEATED
INTERRUPT
?
YES PRESS STOP
NO PRESS START
The agitator has stopped. The following text
appears in the display:
OVERLOADED
SHUT-OFF BOILING PAN
DURING APPROX 1 MIN
PT-1000 FOOD
INTERRUPT
PT-1000 FOOD
SHORT CIRCUIT
PT-1000 ELEMENT
INTERRUPT
PT-1000 ELEMENT
SHORT CIRCUIT
WATER
INTERAPTION
SET WATER
UNSETTABLE DURING
WATER FILLING
TIME TO SERVICE
CONTINUE?
YES, PRESS STOP
EMERGENCY STOP
Red LED in the START button is lit.
Boiling is selected.
The boiling pan does NOT heat up.
19. MESSAGES AND ERROR CODES
The pan is not in working position.
The grid is fully or partly open.
Overheating of heating element.
The heat will shut off in the event
of a fault to the element sensor.
STOP has been pressed dur-
ing operation.
Overloaded agitator
Interrupt in PT-1000 sensor
Short circuit in PT-1000 sensor
Interrupt in PT-1000 sensor
Short circuit in PT-1000 sensor
Fault in water meter
or
no water in to the pan
Manual water filling
in progress
Attained service intervals
The emergency stop is activated
SVI, SPI, during cooling, the boiling
pan has become de-energized.
Message Cause Action
