Electrolux Smart Variomix User Manual

OPERATING INSTRUCTIONS | SMART LINE | BOILING PAN
EN | 02-2015 DOC.N
O
: ST09184-02 25
14.1.2 AGITATION WITHOUT GRID
(SMARTMIX)
This function is used to rotate the agitator when the
grid is open and in the event of tilting.
• Pressthepushbutton and hold to rotate the
agitator at 20 rpm.
• Releasethebutton and the agitator tool will
stop.
14.1.3 Preset agitator program
There are 2 fixed agitator programs and 5 positions
for own programs
• Press Increase speed once.
The following text appears in the display:
PRESET AG.PROGR
MIX
• Press Increase speed until the appropriate
program appears in the display.
When the program to be used appears in the
display:
• Press Agitator start . The agitator starts the
selected program.
• The agitator stops automatically when the pro-
gram has finished.
• You can also stop the agitator with Agitator stop
.
• Changing the speed can be done in each
program.
14.2 Fixed agitator programs
14.2.1 MIX
The fixed program MIX is used to mix more solid
products such as minced meat. Operating time and
pause time are shorter than for normal stirring with
pause.
• Press Increase speed until MIX appears in
the display:
AGITATOR PROGRAM FIXED
MIX
• PressAgitatorstart .
• Press Increase speed and the stirrer starts
at the lowest speed of 25 rpm. (Max speed 100
rpm).
• Press Decrease speed to decrease the
speed.
• PressAgitatorstop to stop the program.
14. AGITATOR
14.1 Agitator Variomix
NOTE: When the agitator is rotating
• Themeasuringstickmustnotbeinthepan
• Do not insert the measuring stick down in the
pan
• Donotinsertanyimplementsdowninthepan
• Donotusethepancolumnsasworksurfaces
• Donottaste
In order to start the agitator the lid or grid must be
closed. Without grid the following text appears in
the display:
AGITATOR
LID/GRID ON
14.1.1 Continuous stirring
• Press Agitator start once. Left LED lights with
a fixed light.
• Press Increase speed and the stirrer starts at
the lowest speed of 25 rpm. (Max. speed 100
rpm.)
• Press Decrease speed to decrease the
speed.
• Press Agitator stop to stop the agitator.
Reverse stirring
• Press Agitator start twice. The LED in the
middle lights.
• Press Increase speed once and the stir-
rer starts at the lowest speed of 25 rpm. (Max
speed 100 rpm.) The agitator rotates clockwise
for 15 seconds, 5 second pause, 15 second an-
ti-clockwise etc.
• Press Decrease speed to decrease the
speed.
• Press Agitator stop to stop the agitator.
Change to pause time
Pause time in the stirring can be altered when the
LED in the middle of the Agitator start is lit:
• Press Agitator start and the right LED also
lights.
The following text appears in the display:
PAUSE TIME Xmin XXs
• PressIncreasevalue to add a longer pause
to the stirring. (Max, 9 min 55 s and min, 0 min
05 s).
Press Decrease value to shorten the pause.
