FloBoss 103/104 Instruction Manual
1-8 General Information Revised August-2017
(DVS) or a Pulse Interface module. Three diagnostic analog inputs (AI)
monitor the battery voltage, logical voltage, and enclosure/battery
temperature. Refer to Chapter 4, Input/Output.
The Local Operator Interface (LOI) port provides a direct, local link
between the FB100-Series and a PC through a Local Operator Interface
cable using EIA-232 (RS-232) communications.
The Comm 1 allows EIA-485 (RS-485) serial communication protocols.
The optional communications card for EIA-232 (RS-232), EIA-485
(RS-485), or dial-up modem activate Comm 2. Refer to Chapter 5,
Communications.
ROCLINK 800
Configuration
Software
The PC-based ROCLINK 800 configuration software enables you to
configure and access the I/O parameters, DVS inputs, flow calculations,
power control, security, and FST programs. Refer to the ROCLINK 800
Configuration Software User Manual (Part D301159X012) for details
concerning software capabilities.
The PC communicates with the FB100-Series through an LOI cable
using EIA-232 (RS-232) communications.
1.2.3 Firmware
The firmware contained in flash ROM on the processor module
determines the functionality of the FB100 and includes:
▪ 1992 AGA-3 flow calculations (with user-selectable AGA8
compressibility Detail, Gross I, or Gross II) for a single meter run
▪ 1996 AGA-7 flow calculations (with user-selectable AGA8
compressibility) for a single meter run.
▪ Memory logging of 240 alarms and 240 events
▪ Archival of minute data from the last 60 minutes for up to 35 points
(Standard History)
▪ Archival of 35 days of hourly data for up to 35 points (Standard
History)
▪ Archival of 35 days of daily data for up to 35 points (Standard
History).
▪ Archival of Min / Max historical data for today and yesterday
(Standard History)
▪ Archival of 5040 entries for up to 15 points at user-specified interval
(Extended History)
▪ Power control (wake up on ring) on optional internal modem
▪ Logic and sequencing control using a user-defined Function
Sequence Table (FST)
▪ Closed-loop (PID) control capabilities (requires optional I/O
termination points)
▪ Communications based on the ROC protocol or Modbus slave, or
optional host, (ASCII or RTU) protocol for use with EFM
applications
