FloBoss 103/104 Instruction Manual
Revised August-2017 Troubleshooting 9-1
Chapter 9 – Troubleshooting
In This Chapter
9.1 Troubleshooting Guidelines ............................................................. 9-1
9.2 Troubleshooting Checklists .............................................................. 9-2
9.2.1 Dial-up Modem ..................................................................... 9-2
9.2.2 Serial Communications ........................................................ 9-2
9.2.3 Optional I/O .......................................................................... 9-2
9.2.4 Software Issues .................................................................... 9-3
9.2.5 Power Issues ........................................................................ 9-3
9.2.6 Dual-Variable Sensor (FB103) ............................................. 9-3
9.2.7 Pulse Interface Module (FB104) .......................................... 9-4
9.2.8 Resistance Temperature Detector ....................................... 9-4
9.3 Procedures ....................................................................................... 9-5
9.3.1 Preserving Configuration and Log Data ............................... 9-5
9.3.2 Resetting the FB100 ............................................................. 9-5
9.3.3 Restarting and Reconfiguring ............................................... 9-6
9.3.4 Connecting the Termination Board to the Backplane .......... 9-7
This chapter provides generalized guidelines for troubleshooting the
FB100. Perform the procedures in this chapter before you remove power
for any reason, after you restore power, and if you disassemble the
FB100.
The following tools are required for troubleshooting:
▪ Personal computer (PC) running Microsoft
®
Windows
®
operating
system
▪ ROCLINK 800 software.
▪ Flat-head and Philips screwdrivers.
9.1 Troubleshooting Guidelines
When you are attempting to diagnose a problem with an FB100:
▪ Remember to write down what steps you have taken.
▪ Save the configuration and log data (see Section 9.3.1).
▪ Note the order in which you remove components.
▪ Note the orientation of the components before you alter or remove
them.
▪ Read and follow all Cautions in this manual.
When you are done troubleshooting, perform the restart and
reconfiguration procedure in Section 9.3.3.
