Projector Parts and Functions
gg Related Links
Name Function
• "Using the Remote Control as a Wireless Mouse" p.68
G
HDMI port Inputs video signals from HDMI compatible video
• "Installing a Security Cable" p.80
equipment and computers.
(EB-X36/EB-X31/EB-
• "Projecting a PC Free Presentation" p.60
S31/EB-W04/EB- The HDMI/MHL port can also input video signals
X04/EB-S04/EB- from MHL (Mobile High-Definition) compatible
W130/EB-X130/EB- mobile devices.
Projector Parts - Base
S130/EB-X350/EB-
This projector is compatible with HDCP.
X300/EB-S300)
HDMI/MHL port
(EB-W32/EB-W31)
HDMI1,
HDMI2/MHL port
(EB-U32/EB-U04/EB-
U130)
H
Computer port Inputs image signals from a computer and component
video signals from other video sources.
I
S-Video port For S-video signals from video sources.
(EB-W32/EB-
W31/EB-X36/EB-
X31/EB-S31/EB-
W04/EB-X04/EB-
S04/EB-W130/EB-
X130/EB-S130/EB-
X350/EB-X300/EB-
S300)
J
USB-B port Connects a USB cable to the computer to project
computer images or to use the Wireless Mouse
function.
K
USB-A port Connects a USB memory device or a digital camera
and projects movies or images using PC Free.
Connects the optional Document Camera.
Connects the wireless LAN module (EB-W31/EB-
Name Function
X36/EB-X31/EB-S31/EB-U04/EB-W04/EB-X04/EB-
S04/EB-U130/EB-W130/EB-X130/EB-S130/EB-
A
Ceiling mount fixing Attach the optional ceiling mount here when
X350/EB-X300/EB-S300).
points (three points) suspending the projector from a ceiling.
Connects the optional Quick Wireless Connection USB
B
Security cable Pass a commercially available wire lock through here
Key.
attachment point and lock it in place.
