Projector Placement
18
Installation space
Attention
Be sure to leave the following amount of space around the projector so as not to
block the air exhaust and intake vents.
A
10 cm
B
20 cm
C
30 cm
Caution
Install the supplied AC adapter more than 30 cm away from the projector. If the
temperature of the AC adapter rises due to heat from the projector, the projector
may not operate properly.
Projection Distance
The distance at which you place the projector from the screen determines the
approximate size of the image. The image size increases the farther the
projector is from the screen, but can vary depending on the aspect ratio and
other settings.
See the Appendix for details about how far to place the projector from the
screen based on the size of the projected image.
a
When correcting keystone distortion, your image is slightly smaller.
gg Related Links
• "Screen Size and Projection Distance" p.87
Installing the Projector on VESA Compliant Mounting
Hardware or a Tripod
You can install the projector onto VESA compliant mounting hardware or a
tripod using the optional or supplied mount plate (ELPMB65).
a
• You can install the projector on VESA compliant (75 × 75mm)
mounting hardware.
• You can install the projector on a tripod for which 1/4-20UNC size
fixed screws can be used.
• When installing the projector in a high place, be sure to install the
optional security wire set (ELPWR01) for safety purposes.
To Next Page
