Appendix
81
Specifications
EH-TW5800/EH-TW5700
Product name
EH-TW5800 EH-TW5700
Appearance
309 (W) x 107 (H) x 308 (D) mm
(not including adjustable foot)
Panel size
0.61" wide
Display method
Polysilicon TFT active matrix
Resolution
1920 (W) x 1080 (H) x 3
Focus adjustment
Manual
Zoom adjustment
Manual (Approx. 1 to 1.6) Manual (Approx. 1 to 1.2)
Lamp (light source)
UHE lamp 200 W
Lamp life expectancy
When Power Consumption is set to High from the Image menu: approx.
4,500 hours
When Power Consumption is set to ECO from the Image menu: approx.
7,500 hours
Power supply
100 - 240 V AC±10%, 50/60 Hz, 3.2 - 1.4 A
Power con-
sumption
100 to 120 V area
Rated power consumption: 310 W
Power consumption when standing by: 0.3 W
220 to 240 V area
Rated power consumption: 297 W
Power consumption when standing by: 0.3 W
Operating altitude
Altitude 0 to 3048 m
Operating temperature
+5 to +35°C (No condensation) (at an altitude of 0 to 2286 m)
+5 to +30°C (No condensation) (at an altitude of 2287 to 3048 m)
Storage temperature
-10 to +60°C (No condensation)
Mass
Approx. 3.8 kg Approx. 3.6 kg
Speaker
10 W x 1 (enclosure)
Connectors
HDMI port 1 HDMI HDCP1.4 supported, CEC signals supported, 3D sig-
nals supported, Linear PCM supported, Deep Color
Audio Out port 1 Stereo mini jack (3.5Φ)
Service port
*
1 USB connector (Type B)
*
Supports USB 2.0. However, USB ports are not guaranteed to operate all devices that support USB.
This product is also designed for IT power distribution system with phase-to-phase voltage 230V.
