User-defined Paper Sizes/
Custom Paper Sizes
You can also print on paper sizes that are not already
available in the printer driver. User-defined paper sizes
that have created and saved as described below can be
selected using the application page setup option. If your
application supports creating user defined sizes, follow
the steps below to select the same size that was created in
the application, and then print.
See the following for information on the paper sizes
supported by this printer.
U “Usable Commercially Papers” on page 113
In addition, the following paper sizes can be selected for
User Defined Paper Size (Windows) or Custom Paper
Sizes (Mac OS X) in the printer driver.
c
Important:
❏ Although you can specify a large paper size
which cannot be loaded on this printer, it will
not be printed properly.
❏ The available output size is limited depending
on the application.
Auto sheet feeder
Width 89.0 to 329.0 mm
Length
89.0 to 3276.7
*1
mm
Roll paper
*2
Width 329.0 mm
Length
55.0 to 3276.7
*1
mm
Front manual feed (poster board)/front manual feed
(fine art media)
Width 210.0 to 329.0 mm
Length
279.4 to 3276.7
*1
mm
1 The maximum length in Mac OS X is 1117.6 mm.
2 The length can be longer than the maximum length specified
if the application supports banner printing. However, the
actual print size depends on the application, the paper size
loaded in the printer, and the computer environment.
Adjusting Settings in Windows
A
When the printer driver's Main screen is
displayed, click User Defined.
U “Basic Printing Methods(Windows)” on
page 31
B
In the User Defined Paper Size screen, set the
paper size you want to use, and then click Save.
❏ You can enter up to 24 single-byte characters
for the Paper Size Name.
❏ The length and width values for a
pre-defined size close to the desired custom
size can be displayed by selecting the
appropriate option in the Base Paper Size
menu.
SC-P600 Series User’s Guide
Printing Varieties
73
