19
SECTION 2 DESCRIPTION
2.1 GENERAL
This manual has been prepared for experienced welders. Do NOT permit untrained persons to install, operate or maintain
this equipment. Do NOT attempt to install or operate this equipment until you have read and fully understand these
instructions.
This manual is intended for use in familiarizing person nel with the design and operation of this equipment. All informa-
tion presented here should be read careful ly before installing and using this equipment.
2.2 RECEIVING-HANDLING
Upon receipt of this equipment, clean all packing material from around the unit and immediately inspect for any damage
that may have occurred during shipment. Any claims for loss or damage occurring in transit must be led with the carrier.
The carrier will furnish a copy of the bill of lading and the freight bill on request, if the need to le a damage claim arises.
When requesting information regarding this equipment, make sure that you include product name, part num ber, and
serial number.
2.3 SAFETY
The safety section at the front of this manual should be read completely before attempting to install and operate this
equipment. Both equipment and person nel hazards are reduced if proper safety precautions are taken. If you are unsure
of yourself in any situa tion, ask your supervisor or other experi enced person nel for help.
Means immediate hazards which, if not
avoided, will result in immediate, serious
personal injury or loss of life.
Means potential hazards which could result
in personal injury or loss of life.
Means hazards which could result in minor
personal injury.
2.4 POWER SOURCE
The power source is a secondary chopper DC output designed for single phase primary connec tions. An ouput controlled
fan provides proper cooling during normal welding operations and shuts o four minutes after welding stops. The fan will
automatically re-start when welding resumes and proper machine temperatures will be maintained.
2.5 WIRE FEEDER
The four (4) roll drive wire feeder is built into the power source cabinet, housed separately from the welding machine electri-
cal components. Cooling air is not drawn through the wire feeder compartment or electronic controls reducing exposure
to dirt and dust which improves product performance and reliability.
The wire feeder pushes wire at speeds from 65 to 675 ipm (inches per minute).
