20
2.6 CONTROLS
The Multimaster 260 can be used to weld solid and ux cored wires. The operator selects the process desired on a three
position switch located on the front panel. A detailed description of the power source controls is included in Section 4
(Operation) of this manual.
2.7 BUILT-IN TOOL BOX
The Multimaster 260 is designed with a lockable storage space on the left side of the machine for welding accessories such
as contact tips, gas nozzles, small grinder, spare parts, welding hood and protective clothing. (Figure 1B)
2.8 GUN MASTER 250 MIG GUN
This air-cooled welding gun is supplied complete and ready to weld .035 in. hard wire. The gun accommodates .045 inch wire
by changing the contact tip. Other wire sizes can be used. Refer to Section 6, for other wire size and alloy accessories.
2.9 RUNNING GEAR
The Multimaster 260 is equipped with running gear with swivel front wheels and a dual gas cylinder support.
SECTION 2 DESCRIPTION
